MYSON Unisenza PLUS Receiver RF

Description

MYSON Unisenza PLUS Receiver RF

The MYSON Unisenza PLUS Receiver RF provides wireless control of a boiler, heat pump, pump or zone valves within a Unisenza PLUS heating system.

Designed to communicate wirelessly with compatible Unisenza PLUS thermostats and electronic thermostatic radiator valves, the Receiver switches on the connected heating equipment when heat is required. Its two-channel design supports heating or cooling control and domestic hot-water scheduling.

The Receiver also features a built-in OpenTherm interface. When connected to a compatible boiler, this enables modulating control, allowing the heat source to adjust its output to demand rather than operating in simple on/off mode.

When used with the Unisenza PLUS Gateway, you can monitor and control the connected heating system remotely via the Unisenza PLUS app.

Key Features

• - Wireless receiver for the Unisenza PLUS control system
• - Controls a compatible boiler, heat pump, pump or zone valves
• - Two channels for heating or cooling and domestic hot-water control
• - Two volt-free relay outputs
• - Built-in OpenTherm controller with automatic interface detection
• - Supports modulating and standard on/off control
• - Compatible with Unisenza PLUS thermostats and electronic thermostatic radiator valves
• - Can connect and control up to 16 Unisenza PLUS eTRVs
• - Local switches for manually overriding each channel
• - App control when connected to the Unisenza PLUS Gateway
• - Supports over-the-air firmware updates
• - Five-year manufacturer’s guarantee

System Compatibility

The Receiver RF is designed for use with the following Unisenza PLUS products:

• Unisenza PLUS Thermostat RF
• Unisenza PLUS Gateway
• Unisenza PLUS Electronic Thermostatic Radiator Valve

In a standard single-zone smart heating system, the Receiver RF connects the Thermostat RF to the boiler or another compatible heat source. The Gateway provides access to the Unisenza PLUS app and compatible smart-home services.

The Receiver can also work with Unisenza PLUS electronic thermostatic radiator valves, enabling the eTRVs to call for heat from the heating source. A Thermostat RF is not required for an eTRV-based system, although one can be added for wider room or zone control.

Installation Information

The Receiver RF requires a 230V electrical supply and must be wired to the relevant boiler, heat pump, pump or zone valves in accordance with the manufacturer’s installation instructions.

The unit provides volt-free relay outputs for standard on/off control and an OpenTherm connection for compatible modulating heat sources. Local switches allow you to override each channel manually during installation, testing, or maintenance.

Electrical installation must be completed by a suitably qualified person. Always isolate the electrical supply before installation or maintenance.

Please note: The Unisenza PLUS Thermostat RF and Gateway are sold separately. They are also available with this Receiver as part of the Unisenza PLUS Central Heating Starter Pack.
