tekmar 260e Single Boiler Controller

Free Delivery from DPD

Description

tekmar 260e Single Boiler Controller

The tekmar  260e replaces existing wiring centres in twin zone and mid position plans to improve the operation of the system, gain efficiency and increase overall comfort. The tekmar  260e is easy to retrofit and boasts a number of energy-saving features.

With your existing boiler, the weather compensation control monitors the outdoor temperature and automatically adjusts the boiler water temperature to match your heating requirements.







Technical Specifications

Controller
Microprocessor PID controller. This is not a safety (limit) control.
Packaged weight
1450 g
Dimensions
170 H x 193 W x 72 D mm
Enclosure
Blue PC+ABS plastic, Nema type 1
Approvals
CE approved
Ambient conditions
Indoor use only, 2 to 50°C, RH 92% Non-condensing up to 40°C
Power supply
230 V (ac) ±10% 50 Hz, 3000 VA max
Controller load
5 VA
Sensors
NTC thermistor, 10k @ 25°C ± 0.2°C ß=3892
Zone valve
230 V (ac), 1 A each (terminals 8 & 12)

Size : tekmar 260e Single Boiler Controller
