ESBE ARA662 Actuator

Image 1 of  ESBE ARA662 Actuator

Frequently brought together:

Description

 ESBE ARA662 Actuator

Series ARA600 with 3-point (open/close) signal is suitable for mixing operations together with valves such as VRG130 and VRB140. In these applications can any position of the actuator operating range be used to get the desired mix level. The compact actuator is designed for operating rotary valves DN 15-50 and has an operating range of 90°. The series can easily be manually operated by the pull-and-turn knob on the front of the cover. Auxiliary switch, available as pre mounted or optional kit can be set in any position and is easily set by a unique solution

Technical Specifications


Voltage V AC 230 Control signal 3-point SPDT
Running Time 90° s 120 Ambient temperature max.: +55 °C / min.: -5 °C
Torque Nm 6 Protection class II
Weight 0.4 kg Rating Auxiliary switch 6(3) A 250 V AC
Enclosure rating IP41 Conformity RoHS 2011/65/EU/ EMC 2014/30/EU/ LVD 2014/35/EU
